- This product is ideal to use as floodlight or emergency lighting in workshops, warehouses, trenches, tunnels and some other public places.
- Has tested function, can quickly test lamps installed function is normal or not.
- The light source adopts the world's most bright LED, the United States CREE brand, power consumption for only 40% of the metal halide lamp.
- Efficient radiator effective solution the LED failure which because of temperature rise, so as to ensure the life to 100,000 hours.
- The transparent part is made of the imported PC materials, with antidazzle design. Featuring gentle light, even lighting and no dazzle, it can effectively avoid visual fatigue caused to operators during the operation.
- Emergency power using lithium-ion polymer battery, safe and effective long service life.
| TECHNICAL SPECIFICATION | |||
|---|---|---|---|
| Parameter | Unit | ZY8810A / ZY8820A | ZY8810B / ZY8820B |
| Output Voltage | VAC | 90-264 | |
| Frequency | Hz | 50Hz / 60Hz | |
| Output Voltage | VDC | 14 | |
| Light power | W | 12 | 6 |
| Luminous | lm | 920 | 640 |
| LED adverage life | h | 100,000 | |
| Emergency time | h | 10 | |
| Charging time | h | 7 | |
| Battery life | Cycle 1000 | ||
| Space Height Ratio | 2 | ||
| Dimension | mm | 180x130x65 | |
| Net Weight | Kg | 2s | |
| ORDERING REFERENCE | ||||||||
|---|---|---|---|---|---|---|---|---|
| Model Number | Type | Light Source | Emergency Wattage | Emergency Duration | Emergency Luminous Flux | Replace Fluorescent Lamp | Energy Saving Lamp | |
| ZY8810A | Normal illuminate + Emergency | LED | 12 | 10 | 1,144 | 36W | 28W | |
| ZY8810B | 6 | 10 | 572 | 18W | 18W | |||
| ZY8810C | 6 | 6 | 572 | 18W | 18W | |||
| ZY8820A | Only Emergency | 12 | 10 | 1,144 | 36W | 28W | ||
| ZY8820B | 6 | 10 | 572 | 18W | 18W | |||
| ZY8820C | 6 | 6 | 572 | 18W | 18W | |||
