- Lighting Hazardous
- >
- LED or Fluorescent
- >
- (here)
- Can be widely used in petroleum, chemical, terminals, ports, aerospace.
- Aviation, military, processing and other places.
- Harsh environment, moist area.
- Gas explosive environment : Group IIA, IIB, IIC.
- Zone 1, Zone2; Zone 21, Zone 22.
- Temperature class: T1 to T6.
- Ceiling, pole, wall mounting type.
- Equipped with world brand light source, electrical appliance.
- Taiwan Meanwell LED driver, power factor >0.98, more stable performance.
- Products using flameproof increased safety structure, easy to install with separate wiring chamber, meet the latest requirements of explosion proof lighting, safe and reliable operation in explosive hazardous areas.
- Light housing made of aluminum alloy, high strength, stainless steel exposed fasteners not color, not rust, can prevent rain .
| TECHNICAL SPECIFICATION | |||
|---|---|---|---|
| Item | Technical specification | Remark | |
| Light source | LED | Fluorescent | T8 LED lamp, T5 fluorescent lamp |
| Rated power | 2×20W、2×10W | 2x28 | - |
| Input voltage range | 100~240VAC | 220~240VAC,110VAC | - |
| Input frequency | 50/60Hz | 50/60Hz | - |
| The entire lighting efficiency | 110lm/W | 60lm/W | - |
| Light source efficiency | 130lm/W | 70lm/W | - |
| CRI (Ra) | 80 | 70 | - |
| Service life (h) | >50000 | >20000 | The light fades less than 30% of the initial value |
| Color Temperature | 4000K | 4000K | 2700-6000k is available as order for led tube |
| Drop cable | Φ10mm-φ14mm | Φ10mm-φ14mm | G3/4”,NPT3/4”,M25 is available as order |
| Terminals | Multi-strand wire:≤2.5mm² / Single-strand wire：≤4mm² | ||
| Dimensions(mm) | 1390mm / 780mm | 1390mm / 780mm | 2x20w / 2x10w |
| Net weight (kg) | 11Kg/7.5Kg | 11Kg/7.5Kg | 2x20w / 2x10w |
